Key Features

1. The entire machine building material is made of 304/316 stainless steel, meeting the GMP and FDA standards. The use of stainless steel enhances the durability and longevity of the machine, making it resistant to corrosion, rust, and other forms of wear and tear.
2. With robust construction, this machine offers simplicity and ease of use. Its user-friendly interface enables operators to quickly understand its functions and operate it efficiently.
3. The servo motor-driven movement and PLC control provided by Panasonic or Siemens in our labeling system guarantees exceptional precision and accuracy. With the integration of these advanced technologies, our label detection system ensures minimal errors during the labeling process, resulting in high-quality and reliable labeling outcomes.
4. Our machine can accommodate various label sizes and shapes without compromising accuracy. Whether it’s round bottles or irregularly shaped containers, our labeling system can adapt effortlessly to meet diverse production requirements.
5. The tool block allows for easy and seamless interchangeability, thereby minimizing downtime and maximizing efficiency.
6. The label positioning device is an innovative solution that offers synchronized adjustment of the lifting position based on the specific shape requirements of different containers. This advanced technology ensures precise and accurate labeling, regardless of the container’s size or shape.
7. Neat and organized entrance with an interlocking acrylic door.
8. Equipping a color Siemens touch screen (HMI) not only simplifies parameter adjustments but also enhances productivity by providing operators with an efficient toolset at their fingertips.

Parameters

More Features

1. Label conveying:The label conveying unit is designed with a single material rack, which has a reasonable height for easy installation of labels. This thoughtful design ensures convenience and efficiency in the labeling process. To ensure smooth and uninterrupted label delivery, a rotating potentiometer is used. This mechanism effectively prevents issues such as incorrect label length or label blocking during the servo delivery process. In case any problem occurs during the labeling operation, the system is equipped with an automatic stop function accompanied by an alarm light. This feature not only alerts operators to potential issues but also provides visual feedback on the touch screen display.
2. Cleaning: The cleaning unit is an essential component of the labeling machine, designed to ensure efficient and precise operation. It incorporates a motor that works in conjunction with a double arc synchronous belt, providing optimal power transmission for the cleaning process. The use of a rubber core, rubber wheel, and tire in this cleaning unit allows for synchronized cleaning action. As the motor drives these components, they work together seamlessly to remove any dirt or debris from the labeling area.
3. Bottle conveying system: The bottle conveying system is an essential component of the overall production line. To achieve this, mechanical transmission is employed to drive the positioning belts on both sides of the system. This mechanism ensures that bottles are accurately positioned and securely held during transportation. When it comes to replacing the entire bottle conveying mechanism, convenience, and precision are prioritized. The control of vertical movement (up and down) as well as width adjustment is facilitated by a handwheel. This handwheel allows operators to synchronize and quickly adjust these parameters according to specific production requirements.
4. Head lifting device:The use of an electric motor in the head lifting device can accurately control the lifting process, improving convenience and efficiency.
5. Bottle shrinking tunnel：The new bottle shrinking tunnel adopts a seamless pipe design, which is widely suitable for round bottles, square bottles, and flat bottles of different shapes and irregular shapes. The whole machine adopts stainless steel material for heat preservation, which is not only energy-saving but also meets international safety standards. The nozzle is divided into three adjustable sections, and the height, position, and steam output of each section can be adjusted separately to achieve a perfect shrinking effect. The stainless steel defrost plate collects condensed water. The low-pressure steam drum is evenly distributed and the steam injection method is unified. The whole machine adopts a waterproof design, which is easy to operate and has a low maintenance cost.
